D5000

Intrinsically Safe Isolators

G.M. International D5000 series uses state-of-the-art solutions to achieve the highest performance for Intrinsically Safe applications; guaranteed by over 15 certification bodies all over the world.

Intrinsically Safe Galvanic Isolators provide the most simple and cost effective means of implementing Intrinsic Safety into Hazardous Area applications.

STRENGTHS

Reduced foot print: high density, 6 mm per channel
Reduced bulk power supply: low power consumption
Reduced cooling needs: low heat dissipation
Higher reliability in & outdoor: certified -40° to + 70° c
Higher resilience to surges: 2.5 Kv isolation
Data guaranteed by 3rd party: SIL 3 (2) TÜV certification
Current & valid standard: certified IEC 61508:2010, Ed.2
Harsh environment resistance: G3 conformal coating
Lower ownership cost: certified for 20 years operation
Reduced spare inventory: universal mounting (stand alone DIN-rail, power bus system and termination boards)
Independent SIL certified dual ch.: dual power supply

Higher reliability In & Outdoor, certified -40°C to +70°C

ENCLOSURE CHARACTERISTICS

High channel density resulting from innovative circuit design using advanced surface mount components
Single, dual, quad and 8 channel models
Plug-in screw terminal blocks to secure wires up to 2.5 mm2
Configuration components are easily accessed by removing the side cover or via connector front panel

STRUCTURE

WIDE FUNCTIONALITY

Modules suitable for SIL 2 and SIL 3 applications according to IEC61508, IEC61511
3 port galvanic isolation to eliminate noise, ground loop problems providing Intrinsic Safety without a high integrity safety earth connection
Line fault alarm detects open or short circuit of field cables
Optional power bus DIN-rail connector
Standard termination board with custom connectors for integration into customized boards
EMC Compatibility to EN61000-6-2, EN61000-6-4, EN61326-1, EN61326-3-1
Wide range DC power supply (18-30 Vdc)
Certified for offshore and maritime applications
