D6000

O D6000

Galvanic Isolators

G.M. International universal mount galvanic isolators provide a simple and cost effective means of implementing isolation in non hazardous applications where SIL certification and/or high reliability are a requirement.

STRENGTHS

Data guaranteed by 3rd party, SIL 3 (2) TÜV certification
Reduced foot print, high density: 1, 2, 4 or 8 ch. each
Simplified installation/config, DIP switch configurability
Faster reaction time, lower down time
Lower cost of ownership, certified for 20 years operation
Reduced spare inventory, universal mounting
Improved reliability, low power consumption and heat dissipation
RS-485 Modbus output version available

Operating temperature certified from -40°C to +70°C

ENCLOSURE CHARACTERISTICS

- High channel density (3/6/12 mm per channel) resulting from innovative circuit design using advanced surface mount components
- Single, dual, quad or 8 channel models
- Plug-in screw terminal blocks to secure wires up to 2.5 mm2
- Configuration components are easily accessed by removing the side cover or via connector front panel

STRUCTURE

WIDE FUNCTIONALITY

Modules suitable for SIL 2 applications according to IEC61508, IEC61511
3 port galvanic isolation to eliminate noise, ground loop problems
Line fault alarm detects open or short circuit of field cables
Optional power bus DIN-rail connector
Standard termination board with custom connectors for integration into customized boards
EMC compatibility to EN61000-6-2, EN61000-6-4, EN61326-1, EN61326-3-1
DIP switch configurability for easy field setup
Modules accept DC power supply over a wide range for 24 Vdc (18-30 Vdc) applications

LONGER LIFETIME

Capability to withstand higher temperatures, improves the lifetime in normal conditions
Very high reliability in extreme environment applications
G3 conformal coating
Reduced cabinet dimensions, require less ventilation
